Model Specs:

More Info
  • Machined, anodized, aluminum spool.
  • Four aircraft-grade, shielded, stainless steel ball bearings.
  • Lightweight graphite frame.
  • Stainless steel reel stand.
  • Powerful 120 angle drag quadrant.
  • Push-button shift system on all 2-speed models.
Mono Cap
(yds/lb)
Braid Cap
(yds/lb)
Bearings Max Drag Gear Ratio Line Retrieve
675/20
450/30
380/40
925/50
775/65
675/80
4 14 3.8:1 32 / 17
Availability SKU Name Our Price
International Reel Not Shifting?   International VS or GLD Reel Not Shifting?
1M-15KG Discontinued. Still In Stock. Limit 1 1M-15KG
1180573
1M-15KG Plate, Handle Side Plate Assembly

REPLACES ORIGINAL NUMBER 1-15KG ON SOME REELS

$45.50 More Info
2M-15KG In Stock 2M-15KG
1180663
2M-15KG Ring, Quadrant Ring, Matte

REPLACES ORIGINAL NUMBER 2-15KG ON SOME REELS

Direct product replacement: 2-15KG Ring, Quadrant Ring, Chrome Finish (Original) $13.25
$14.90 More Info
3-15KG In Stock 3-15KG
1180673
3-15KG Bridge, Dog Bridge $4.60 More Info
5-10LD Backordered. Still In Stock. Limit 2 5-10LD
1180805
5-10LD Gear, Main Gear

MULTI USE See Description

Used on multiple models in different quantities.
$25.15 More Info
6-15KG In Stock 6-15KG
1180901
6-15KG Washer, Drag HT-100™ $12.45 More Info
7-15KG In Stock 7-15KG
1181000
7-15KG Washer, Drag, Metal Drag Washer $18.00 More Info
13-15KG In Stock 13-15KG
1181282
13-15KG Gear, Pinion Gear $40.35 More Info
013C015KG Discontinued. Still In Stock. Limit 2 013C015KG
1181374
13C-15KG Assembly, Pinion Gear Assembly
This part will no longer be manufactured by Penn; Limited Quantities Available
$51.30 More Info
14-15KG In Stock 14-15KG
1181387
14-15KG Spring, Dog Spring (uses 2) $1.15 More Info
15-15KG In Stock 15-15KG
1181419
15-15KG Dog (uses 2) $1.35 More Info
16T-60CH In Stock 16T-60CH
1181591
16T-60CH Screw, Side Plate Screw (uses 2) $1.15 More Info
18-50TW In Stock 18-50TW
1181613
18-50TW Spring, Clutch, Disc Clutch Spring, Heavy (.044 in or 1.13 mm thick) (uses 2) $1.70 More Info
20-4200 In Stock 20-4200
1181780
20-4200 Bearing, Ball Bearing
Used on multiple models in different quantities.
$11.60 More Info
21-15KG In Stock 21-15KG
1181822
21-15KG Eccentric Lever $7.35 More Info
23M-114 Discontinued. Still In Stock. Limit 5 23M-114
1181961
23M-114 Screw, Handle Screw, Matte Fin. with Oiler

MULTI USE See Description

113H Fits All Versions.
$8.95 More Info
24C-50 Discontinued. Not Available 24C-50 24C-50 Cap, Handle Knob Cap, Plastic

Replaced by 24C-50M
Direct product replacement: 24C-50M Cap, Handle Knob Cap, Rubber $2.90
More Info
24C-50M In Stock 24C-50M
1191334
24C-50M Cap, Handle Knob Cap, Rubber

REPLACES ORIGINAL NUMBER 24C-50 ON SOME REELS

$2.90 More Info
24M-15LD Discontinued. Still In Stock. Limit 1 24M-15LD 24M-15LD Handle, Matte Metal, Large Plastic Knob
FITS: Type [L] Bridge/Sleeve

LIMITED QUANTITIES AVAILABLE

$45.70 More Info
24M-15LD-1 Discontinued. Still In Stock. Limit 2 24M-15LD-1
1223799
24M-15LD-1 Blank, Handle, Matte $13.00 More Info
24MN-15LD Discontinued. Still In Stock. Limit 2 24MN-15LD
1182095
24MN-15LD Handle, Matte Metal, Large Rubberized Knob
FITS: Type [L] Bridge/Sleeve
$48.00 More Info
25-50  Discontinued. Not Available 25-50
1182103
25-50 Knob, Handle Knob, Original Hard Plastic

REPLACED BY PART NUMBER 25-50M

More Info
25-50M Discontinued. Not Available 25-50M
1191345
25-50M Knob, Handle, Soft Grip

REPLACES ORIGINAL NUMBER 25-50 ON SOME REELS

More Info
25S-50M In Stock 25S-50M
1206009
25S-50M Knob, Handle, Soft Grip, Stainless Stud

REPLACES ORIGINAL PART NUMBER 25-50M ON SOME REELS

$18.30 More Info
25-50VISSP In Stock 25-50VISSP 25-50VISSP VIS Molded Knob Assembly KIT
This is also an UPGRADED knob kit for any older Penn reel that uses the 91N-50 Rivet
$28.90 More Info
26-15KG In Stock 26-15KG
1182110
26-15KG Bushing $2.85 More Info
26-40 In Stock 26-40
1182112
26-40 Bearing, Ball Bearing $15.90 More Info
29L-10LD In Stock 29L-10LD
1182475
29L-10LD Spool, Aluminum (Black) $59.60 More Info
31T-15KG In Stock 31T-15KG
1182698
31T-15KG Screw, Long (uses 2) $1.90 More Info
32-2 In Stock 32-2
1182706
32-2 Screw

MULTI USE See Description

Used on multiple models in different quantities.
$1.15 More Info
33-16VS In Stock 33-16VS
1191592
33-16VS Clamp, Rod Clamp with Ring (Thick) (Iron Alloy) (Grey)

REPLACES ORIGINAL NUMBERS 33-16S, 33-TRQS ON SOME REELS

$19.90 More Info
33-113 Discontinued. Still In Stock. Limit 5 33-113
033-33-113
33-113 Clamp, Rod Clamp (Thick) (Graphite) (Black)

REPLACED BY PART NUMBER 33N-113

$5.75 More Info
33N-113 In Stock 33N-113
1182754
33N-113 Clamp, Rod Clamp with Side Ring (Thick) (Graphite) (Black)

REPLACES ORIGINAL NUMBER 33-113 ON SOME REELS

$5.35 More Info
33-TRQ In Stock 33-TRQ
1290729
33-TRQ Clamp, Rod Clamp (Thick) (Aluminum) (Black) $1.50 More Info
33-TRQS In Stock 33-TRQS
1365544
33-TRQS Clamp, Rod Clamp (Thick) (Aluminum) (Silver) $8.50 More Info
34-10KG In Stock 34-10KG
1191620
34-10KG Screw, Clamp Screw (uses 2)

114 Fits 2nd Generation Half Frame with drag washers accessible on the outside of the reel.
$2.90 More Info
34C-10KG In Stock 34C-10KG
1191645
34C-10KG, Screw With Nuts
114 Fits 2nd Generation Half Frame with drag washers accessible on the outside of the reel.
$5.65 More Info
35-310N  In Stock 35-310N
1182922
35-310N Tongue, Click Tongue

NEW System on 330GT and 330LD Reels
$2.05 More Info
36-15KG Discontinued. Still In Stock. Limit 2 36-15KG
1182975
36-15KG Button, Click Button $4.25 More Info
37EGLD-20 In Stock 37EGLD-20
1183126
37EGLD-20 Bar, Top Spacer Bar with Model # $56.70 More Info
39T-15KG In Stock 39T-15KG
1183262
39T-15KG Screw, Bridge Screw $1.15 More Info
41-15KG In Stock 41-15KG
1183320
41-15KG Spindle Spring $6.75 More Info
46T-750 In Stock 46T-750
1183588
46T-750 Screw, Short (uses 2) $1.15 More Info
46T-9500 In Stock 46T-9500
1183589
46T-9500 Screw, Frame, Long (uses 2) $1.15 More Info
50M-15KG In Stock 50M-15KG
1183777
50M-15KG Shield, Gear Stud Shield, Matte Finish $3.50 More Info
54M-15KG In Stock 54M-15KG
1183870
54M-15KG Lug, Harness (uses 2)

REPLACES ORIGINAL NUMBER 54-15KG ON SOME REELS

$3.70 More Info
55-50 In Stock 55-50
1183876
55-50 Bearing, Ball Bearing

MULTI USE See Description

Used on multiple models in different quantities.
$19.90 More Info
62-545 In Stock 62-545
1184029
62-545 Spring, Click Spring
Used on multiple models in different quantities.
$1.15 More Info
62B-525 In Stock 62B-525
1184037
62B-525 Pin, Click Pin (uses 2) $1.70 More Info
62C-15KG Discontinued. Still In Stock. Limit 2 62C-15KG
1184039
62C-15KG Cover, Click Spring Cover (uses 2)

LIMITED QUANTITIES AVAILABLE

$1.50 More Info
63-50 In Stock 63-50
1184046
63-50 Screw, Short, Handle Knob Screw $1.35 More Info
63-500S In Stock 63-500S
1184052
63-500S Screw

MULTI USE See Description

Used on multiple models in different quantities.
$1.20 More Info
63A-50 In Stock 63A-50
1184056
63A-50 Screw, Long, Handle Stud
Used on multiple models in different quantities.
$1.70 More Info
69B-50 In Stock 69B-50
1184125
69B-50 Ring, Retaining Ring (E-Clip) $1.15 More Info
69B-600 1184129 In Stock 69B-600 1184129
DSS-VP2041
69B-600 | DSS-VP2041 Ring, Retaining Ring (E-clip)
Used on multiple models in different quantities.
$1.35 More Info
69C-15KG In Stock 69C-15KG
1184130
69C-15KG Ring, Spindle Retaining Ring $2.55 More Info
69D-15KG In Stock 69D-15KG
1184135
69D-15KG Ring, Retaining Ring $1.35 More Info
71-10KG In Stock 71-10KG
1184146
71-10KG Spindle, Spool Spindle $12.45 More Info
81-40 In Stock 81-40
1184203
81-40 Ratchet, Click Ratchet $5.35 More Info
91N-50 In Stock 91N-50
1184304
91N-50 Handle Rivet $10.30 More Info
101-30 In Stock 101-30
1184403
101-30 Screw, Torx Head Screw
Used on multiple models in different quantities.
$1.15 More Info
110-50 In Stock 110-50
1184436
110-50 Screw
Used on multiple models in different quantities.
$1.15 More Info
110M-50 In Stock 110M-50
1184448
110M-50 Plate, Locking, Handle Locking Plate $3.70 More Info
117-15KG In Stock 117-15KG
1184472
117-15KG Drive Plate $18.90 More Info
117A-15KG Discontinued. Still In Stock. Limit 1 117A-15KG
1192257
117A-15KG Plate Assembly Drive
This part will no longer be manufactured by Penn; Limited Quantities Available.
$63.00 More Info
124-15KG In Stock 124-15KG
1184534
124-15KG Cover, Bridge Cover $6.95 More Info
134-10LD Discontinued. Still In Stock. Limit 1 134-10LD
1184605
134-10LD Stud, Gear Stud $14.60 More Info
141-15KG In Stock 141-15KG
1184647
141-15KG Cam Follower $4.15 More Info
144M-15KG Backordered. Still In Stock. Limit 2 144M-15KG
1184698
144M-15KG Knob, Preset Knob (Silver)

LIMITED QUANTITIES AVAILABLE

REPLACES ORIGINAL NUMBER 144-15KG ON SOME REELS

$24.00 More Info
149-45 In Stock 149-45
1184702
149-45 Nut, Clamp, Long, for Thick Clamps (uses 2)
Used with the graphite clamps 33-114H2, 33-340, 33N-113 and the iron alloy clamp 33i-113
$1.45 More Info
156-15KG Backordered. Not Available 156-15KG
1184730
156-15KG Cover, Drag Cover More Info
157-15KG In Stock 157-15KG
1184762
157-15KG Bushing, Spacer Bushing $5.55 More Info
157-50 In Stock 157-50
1184764
157-50 Bushing, Spacer Bushing

LIMITED QUANTITIES AVAILABLE

Used on multiple models in different quantities.
$2.70 More Info
161-25 In Stock 161-25
1184785
161-25 Button, Free Spool Button $2.70 More Info
161-40 In Stock 161-40
1184787
161-40 Button, Strike Button $3.00 More Info
162-50 In Stock 162-50
1184795
162-50 Spring
Used on multiple models in different quantities.
$1.15 More Info
183M-10KG Discontinued. Still In Stock. Limit 1 183M-10KG
1184868
183M-10KG Frame

REPLACES ORIGINAL NUMBER 183-10KG ON SOME REELS

$60.95 More Info
Misc. Discontinued. Not Available Misc. 111-50 Reel Bag, Gold $0.00 More Info
PEN SMLRC In Stock PEN SMLRC
1178861
SMLRC Cover, Reel Cover, Conventional, Size Small

FITS REELS:
10LD, 10KG, 12LT, 12H, 12V, 12VS, 12VSX, 15LD, 16S, 16VS, 16VSX
20T, 30T, 30TW, 30VSX
113, 113L2, 113H, 113H2, 113HSP, 113H2SP, 113HLW, 113H2LW, 113HN, 113MTL, US113, US113N, US113W
220GTO, 230GTO
330GT, 330GT2, 330LD
DFN25LW, DFN30, DFN40LW
FTH25LW, FTH40LW, FTH60LW
GLD20, GLD20ii
SQL16VS. SQL25N, SQL30, SQL30LD, SQL40, SQL40LD, SQL40LDLH
WAR15LWLC, WAR15LWLCLC, WAR20LWLC, WAR20LWLCLH

$15.49 More Info
