Model Specs:

More Info
  • Machined, anodized, aluminum spool.
  • Four aircraft-grade, shielded, stainless steel ball bearings.
  • Lightweight graphite frame.
  • Stainless steel reel stand.
  • Powerful 120 angle drag quadrant.
  • Push-button shift system on all 2-speed models.
Mono Cap
(yds/lb)
Braid Cap
(yds/lb)
Bearings Max Drag Gear Ratio Line Retrieve
600/30
500/40
370/50
1025/65
875/80
750/100
4 17 3.8:1 32 / 17
Availability SKU Name Our Price
International Reel Not Shifting?   International VS or GLD Reel Not Shifting?
1M-15KG Discontinued. Still In Stock. Limit 1 1M-15KG
001M-1180573
1M-15KG Plate, Handle Side Plate Assembly

REPLACES ORIGINAL NUMBER 1-15KG ON SOME REELS

$45.50 More Info
2M-15KG In Stock 2M-15KG
002M-1180663
2M-15KG Ring, Quadrant Ring, Matte

REPLACES ORIGINAL NUMBER 2-15KG ON SOME REELS

Direct product replacement: 2-15KG Ring, Quadrant Ring, Chrome Finish (Original) $13.25
$14.90 More Info
3-15KG In Stock 3-15KG
003-1180673
3-15KG Bridge, Dog Bridge $4.60 More Info
5-10LD Backordered. Still In Stock. Limit 2 5-10LD
005-1180805
5-10LD Gear, Main Gear

MULTI USE See Description

Used on multiple models in different quantities.
$25.15 More Info
6-15KG In Stock 6-15KG
006-1180901◉
6-15KG Washer, Drag HT-100™ $12.45 More Info
7-15KG In Stock 7-15KG
007-1181000▲
7-15KG Washer, Drag, Metal Drag Washer $18.00 More Info
13-15KG In Stock 13-15KG
013-1181282
13-15KG Gear, Pinion Gear $40.35 More Info
013C-015KG Discontinued. Still In Stock. Limit 2 013C-015KG
013C-1181374
13C-15KG Assembly, Pinion Gear Assembly $51.30 More Info
14-15KG In Stock 14-15KG
014-1181387☀
14-15KG Spring, Dog Spring (uses 2) $1.15 More Info
15-15KG In Stock 15-15KG
015-1181419☀
15-15KG Dog (uses 2) $1.35 More Info
16T-60CH In Stock 16T-60CH
016T-1181591
16T-60CH Screw, Side Plate Screw (uses 2) $1.15 More Info
18-50TW In Stock 18-50TW
018-1181613☀
18-50TW Spring, Clutch, Disc Clutch Spring, Heavy (.044 in or 1.13 mm thick) (uses 2) $1.70 More Info
20-4200 In Stock 20-4200
020-1181780☀
20-4200 Bearing, Ball Bearing
Used on multiple models in different quantities.
$11.60 More Info
21-15KG In Stock 21-15KG
021-1181822
21-15KG Eccentric Lever $7.35 More Info
23M-114 Discontinued. Still In Stock. Limit 5 23M-114
023M-1181961☀
23M-114 Screw, Handle Screw, Matte Fin. with Oiler

MULTI USE See Description

113H Fits All Versions.
$8.95 More Info
24C-50 Discontinued. Not Available 24C-50
024C-24C-50
24C-50 Cap, Handle Knob Cap, Plastic

Replaced by 24C-50M
Direct product replacement: 24C-50M Cap, Handle Knob Cap, Rubber $2.90
More Info
24C-50M In Stock 24C-50M
024C-1191334☀
24C-50M Cap, Handle Knob Cap, Rubber

REPLACES ORIGINAL NUMBER 24C-50 ON SOME REELS

$2.90 More Info
24M-15LD Discontinued. Still In Stock. Limit 1 24M-15LD
024M-24M-15LD
24M-15LD Handle, Matte Metal, Large Plastic Knob
FITS: Type [L] Bridge/Sleeve

LIMITED QUANTITIES AVAILABLE

$45.70 More Info
24MN-15LD Discontinued. Still In Stock. Limit 2 24MN-15LD
024MN-1182095
24MN-15LD Handle, Matte Metal, Large Rubberized Knob
FITS: Type [L] Bridge/Sleeve
$48.00 More Info
24M-15LD-1 Discontinued. Still In Stock. Limit 2 24M-15LD-1
024M-1223799
24M-15LD-1 Blank, Handle, Matte $13.00 More Info
25-50 Discontinued. Not Available 25-50
025-1182103
25-50 Knob, Handle Knob, Original Hard Plastic

REPLACED BY PART NUMBER 25-50M

More Info
25-50M Discontinued. Not Available 25-50M
025-1191345
25-50M Knob, Handle, Soft Grip

REPLACES ORIGINAL NUMBER 25-50 ON SOME REELS

More Info
25S-50M Backordered. Still In Stock. Limit 10 25S-50M
025S-1206009
25S-50M Knob, Handle, Soft Grip, Stainless Stud

REPLACES ORIGINAL PART NUMBER 25-50M ON SOME REELS

$18.30 More Info
25-50ViSSP In Stock 25-50ViSSP
025-50ViSSP▭
25-50ViSSP VIS Molded Knob Assembly KIT
This is also an UPGRADED knob kit for any older Penn reel that uses the 91N-50 Rivet
$28.90 More Info
26-15KG In Stock 26-15KG
026-1182110
26-15KG Bushing $2.85 More Info
26-40 In Stock 26-40
026-1182112☀
26-40 Bearing, Ball Bearing $15.90 More Info
29L-15LD In Stock 29L-15LD
029L-1182479
29L-15LD Spool, Aluminum (Black)

REPLACES ORIGINAL NUMBER 29L-15KG

$61.20 More Info
31T-15KG In Stock 31T-15KG
031T-1182698
31T-15KG Screw, Long (uses 2) $1.90 More Info
32-2 In Stock 32-2
032-1182706☀
32-2 Screw

MULTI USE See Description

Used on multiple models in different quantities.
$1.15 More Info
33-340 Backordered. Not Available 33-340
033-1182760
33-340 Clamp, Rod, Graphite
114 Fits All Versions.
114H Fits All Versions.
Direct product replacement: 33-114H2 Clamp, Rod Clamp, Graphite with ring $12.55
More Info
33C-114 Discontinued. Still In Stock. Limit 1 33C-114
033C-114▭
33C-114 Clamp, Rod, KIT: Graphite Clamp with Studs, Nuts and Wrench
114 Fits 2nd Generation Half Frame and Full Frame Versions.
114H Fits Half Frame and Full Frame Versions.
$21.70 More Info
33C-114HF Discontinued. Not Available 33C-114HF
033C-1182776
33C-114HF Graphite Clamp with Studs, Nuts and Wrench
114 Fits 2nd Generation Half Frame and Full Frame Versions.
114H Fits Half Frame and Full Frame Versions.
More Info
34-10KG In Stock 34-10KG
034-1191620▲
34-10KG Screw, Clamp Screw (uses 2)

114 Fits 2nd Generation Half Frame with drag washers accessible on the outside of the reel.
$2.90 More Info
34C-10KG In Stock 34C-10KG
034C-1191645
34C-10KG, Screw With Nuts
114 Fits 2nd Generation Half Frame with drag washers accessible on the outside of the reel.
$5.65 More Info
35-310N In Stock 35-310N
035-1182922☀
35-310N Tongue, Click Tongue

NEW System on 330GT and 330LD Reels
$2.05 More Info
36-15KG Discontinued. Still In Stock. Limit 2 36-15KG
036-1182975
36-15KG Button, Click Button $4.25 More Info
37EGLD-30 In Stock 37EGLD-30
037EGLD-1183128
37EGLD-30 Bar, Top Spacer Bar with Model # $52.95 More Info
39T-15KG In Stock 39T-15KG
039T-1183262
39T-15KG Screw, Bridge Screw $1.15 More Info
41-15KG In Stock 41-15KG
041-1183320
41-15KG Spindle Spring $6.75 More Info
46T-750 In Stock 46T-750
046T-1183588
46T-750 Screw, Short (uses 2) $1.15 More Info
46T-9500 In Stock 46T-9500
046T-1183589
46T-9500 Screw, Frame, Long (uses 2) $1.15 More Info
50M-15KG In Stock 50M-15KG
050M-1183777
50M-15KG Shield, Gear Stud Shield, Matte Finish $3.50 More Info
54M-15KG In Stock 54M-15KG
054M-1183870
54M-15KG Lug, Harness (uses 2)

REPLACES ORIGINAL NUMBER 54-15KG ON SOME REELS

$3.70 More Info
55-50 In Stock 55-50
055-1183876▲
55-50 Bearing, Ball Bearing

MULTI USE See Description

Used on multiple models in different quantities.
$19.90 More Info
62-545 In Stock 62-545
062-1184029☀
62-545 Spring, Click Spring
Used on multiple models in different quantities.
$1.15 More Info
62B-525 In Stock 62B-525
062B-1184037☀
62B-525 Pin, Click Pin (uses 2) $1.70 More Info
62C-15KG Discontinued. Still In Stock. Limit 2 62C-15KG
062C-1184039
62C-15KG Cover, Click Spring Cover (uses 2)

LIMITED QUANTITIES AVAILABLE

$1.50 More Info
63-50 In Stock 63-50
063-1184046☀
63-50 Screw, Short, Handle Knob Screw $1.35 More Info
63-500S In Stock 63-500S
063-1184052☀
63-500S Screw

MULTI USE See Description

Used on multiple models in different quantities.
$1.20 More Info
63A-50 In Stock 63A-50
063A-1184056☀
63A-50 Screw, Long, Handle Stud
Used on multiple models in different quantities.
$1.70 More Info
69B-50 In Stock 69B-50
069B-1184125☀
69B-50 Ring, Retaining Ring (E-Clip) $1.15 More Info
69B-600 1184129 In Stock 69B-600 1184129
69B-1184129♦
69B-600 | DSS-VP2041 Ring, Retaining Ring (E-clip)
Used on multiple models in different quantities.
$1.35 More Info
69C-15KG In Stock 69C-15KG
069C-1184130☀
69C-15KG Ring, Spindle Retaining Ring $2.55 More Info
69D-15KG In Stock 69D-15KG
069D-1184135
69D-15KG Ring, Retaining Ring $1.35 More Info
71-15KG In Stock 71-15KG
071-1184147
71-15KG Spindle, Spool Spindle $13.20 More Info
81-40 In Stock 81-40
081-1184203▲
81-40 Ratchet, Click Ratchet $5.35 More Info
91N-50 Backordered. Still In Stock. Limit 2 91N-50
091N-1184304
91N-50 Handle Rivet $10.30 More Info
101-30 In Stock 101-30
101-1184403☀
101-30 Screw, Torx Head Screw
Used on multiple models in different quantities.
$1.15 More Info
110-50 In Stock 110-50
110-1184436☀
110-50 Screw
Used on multiple models in different quantities.
$1.15 More Info
110M-50 In Stock 110M-50
110M-1184448
110M-50 Plate, Locking, Handle Locking Plate $3.70 More Info
117-15KG In Stock 117-15KG
117-1184472
117-15KG Drive Plate $18.90 More Info
117A-15KG Discontinued. Still In Stock. Limit 1 117A-15KG
117A-1192257
117A-15KG Plate Assembly Drive
This part will no longer be manufactured by Penn; Limited Quantities Available.
$63.00 More Info
124-15KG In Stock 124-15KG
124-1184534
124-15KG Cover, Bridge Cover $6.95 More Info
134-10LD Discontinued. Still In Stock. Limit 1 134-10LD
134-1184605
134-10LD Stud, Gear Stud $14.60 More Info
141-15KG In Stock 141-15KG
141-1184647☀
141-15KG Cam Follower $4.15 More Info
144M-15KG Backordered. Still In Stock. Limit 2 144M-15KG
144M-1184698
144M-15KG Knob, Preset Knob (Silver)

LIMITED QUANTITIES AVAILABLE

REPLACES ORIGINAL NUMBER 144-15KG ON SOME REELS

$24.00 More Info
149-45 In Stock 149-45
149-1184702♦
149-45 Nut, Clamp, Long, for Thick Clamps (uses 2)
Used with the graphite clamps 33-114H2, 33-340, 33N-113 and the iron alloy clamp 33i-113
$1.45 More Info
157-15KG In Stock 157-15KG
157-1184762
157-15KG Bushing, Spacer Bushing $5.55 More Info
157-50 In Stock 157-50
157-1184764☀
157-50 Bushing, Spacer Bushing

LIMITED QUANTITIES AVAILABLE

Used on multiple models in different quantities.
$2.70 More Info
161-25 In Stock 161-25
161-1184785
161-25 Button, Free Spool Button $2.70 More Info
161-40 In Stock 161-40
161-1184787
161-40 Button, Strike Button $3.00 More Info
162-50 In Stock 162-50
162-1184795☀
162-50 Spring
Used on multiple models in different quantities.
$1.15 More Info
156-15KG Backordered. Not Available 156-15KG
156-1184730
156-15KG Cover, Drag Cover More Info
168-116 In Stock 168-116
168-1192372
168-116 Double Open End Wrench $1.15 More Info
183M-15KG In Stock 183M-15KG
183M-1184933
183M-15KG Frame, Matte Finish $76.00 More Info
PEN MEDRC In Stock PEN MEDRC
1178862
MEDRC Cover, Reel Cover, Conventional, Size Medium

FITS REELS:
15LD, 15KG, 24KG
20, 30 INT, 30S, 30SW, 30T, 30TW, 30VW, 30VSW
50S, 50T, 50ST, 50VSX
114, 114L2, 114H, 114H2, 114H2SP, 114HLW, 114H2LW
340GT, 340GT2, 345GT, 345GT2
FTH60LW
GLD30, GLD30ii
SQL30VSW, SQL50LD, SQL60LD, SQL60LDLH

$15.49 More Info
