Model Specs:

More Info
  • Lightweight graphite frames and sideplates
  • Forged and machined aluminum spool
  • High-strength marine grade bronze main and pinion gear
  • Dura-Drag washers virtually elimite hesitation, even under extreme drag settings
  • Switchblade harness lugs on 50 and 60 size models
  • Ratched drag lever prevents "drag creep" caused by hours of trolling and vibrations
  • Line Capacity Rings
  • 5+1 shielded stainless steel bearing system
  • Instant anti-reverse bearing with silent back up ratchet
Mono Cap
(yds/lb)
Braid Cap
(yds/lb)
Bearings Max Drag at Strike Max Drag at Full Gear Ratio Line Retrieve
390/20
350/25
260/30
1025/20
775/30
550/30
5+1 9 lbs 13 lbs 6.1:1 37
Availability SKU Name Our Price
1-30SLD In Stock 1-30SLD
001-1238901
1-30SLD Plate Assembly Right Side $23.35 More Info
2-30SLD In Stock 2-30SLD
002-1238904
2-30SLD Ring, Right Side $9.50 More Info
2A-30SLD In Stock 2A-30SLD
002A-1238905
2A-30SLD Ring, Quadrant Ring $2.70 More Info
3-30SLD In Stock 3-30SLD
003-1257813
3-30SLD Dog Bridge Assembly $11.30 More Info
4-25 In Stock 4-25
004-1180750
4-25 Washer, Gear Stud Washer $1.15 More Info
5-30SLD In Stock 5-30SLD
005-1238907
5-30SLD Gear, Main $18.85 More Info
8-30SLD In Stock 8-30SLD
008-1257843☀
8-30SLD Washer, Crescent Washer $1.15 More Info
13-30SLD In Stock 13-30SLD
013-1238908
13-30SLD Pinion $8.85 More Info
13B-30SLD In Stock 13B-30SLD
013B-1257816
13B-30SLD Sleeve, Spindle $1.70 More Info
16-975LD In Stock 16-975LD
016-1181587
16-975LD Screw

MULTI USE See Description

Used on multiple models in different quantities.
$1.15 More Info
18-30SLD In Stock 18-30SLD
018-1238909☀
18-30SLD Washer, Spring (uses 4) $2.70 More Info
21-30SLD In Stock 21-30SLD
021-1238910
21-30SLD Lever, Drag $6.95 More Info
23-6CH In Stock 23-6CH
023-1181930☀
23-6CH Screw, Gear Mounting Screw $2.55 More Info
23-TRQ40 In Stock 23-TRQ40
023-1229462☀
23-TRQ40 Handle Nut (Black) $3.80 More Info
24-TRQ40 Backordered. Not Available 24-TRQ40
024-1229501▭
24-TRQ40 Handle, Black Football Knob (Black/Gold)
FITS: Type [E] Bridge/Sleeve
More Info
28-30SLD In Stock 28-30SLD
028-1238922
28-30SLD Ring, Left Side $9.50 More Info
29L-30SLD In Stock 29L-30SLD
029L-1238923
29L-30SLD Spool $41.95 More Info
32-15 In Stock 32-15
032-1182708☀
32-15 Screw, Short, Pan Head
Used on multiple models in different quantities.
$1.15 More Info
32-30SLD In Stock 32-30SLD
032-1238924☀
32-30SLD Screw (uses 3) $1.15 More Info
32-310 In Stock 32-310
032-1182722☀
32-310 Screw
Used on multiple models in different quantities.
$1.15 More Info
33-16VS In Stock 33-16VS
033-1191592▲
33-16VS Clamp, Rod Clamp with Ring (Thick) (Iron Alloy) (Grey)

REPLACES ORIGINAL NUMBERS 33-16S, 33-TRQS ON SOME REELS

$19.90 More Info
33-113 Discontinued. Not Available 33-113
033-113
33-113 Clamp, Rod Clamp (Thick) (Graphite) (Black)

REPLACED BY PART NUMBER 33N-113

More Info
33-TRQ In Stock 33-TRQ
033-1290729▲
33-TRQ Clamp, Rod Clamp (Thick) (Aluminum) (Black) $1.50 More Info
33-TRQS In Stock 33-TRQS
033-1365544▲
33-TRQS Clamp, Rod Clamp (Thick) (Aluminum) (Silver) $8.50 More Info
33N-113 In Stock 33N-113
033N-1182754☘
33N-113 Clamp, Rod Clamp with Side Ring (Thick) (Graphite) (Black)

REPLACES ORIGINAL NUMBER 33-113 ON SOME REELS

$5.35 More Info
33C-30SLD In Stock 33C-30SLD
033C-1238925
33C-30SLD Kit, Clamp, Rod Clamp with Ring (Thick) (Graphite) (Black) (7pc Kit) $13.30 More Info
34-45 In Stock 34-45
034-1182788▲
34-45 Screw, Rod Clamp Screw (Shorter for Thick Clamps) ONLY (uses 2)

This is just the stud

114 Fits Frame Posts Version.
114H Fits Frame Posts Version.
$1.35 More Info
34C-45 In Stock 34C-45
034C-1182862▲
34C-45 Screw With Nuts, for Thick Style Rod Clamp (uses 2)
114 Fits Frame Posts Version.
114H Fits Frame Posts Version.
$5.30 More Info
35-30SLD In Stock 35-30SLD
035-1238939☀
35-30SLD Tongue, Click $1.70 More Info
36-30SLD Backordered. Still In Stock. Limit 2 36-30SLD
036-1238940
36-30SLD Button, Click $5.00 More Info
37-30SLD In Stock 37-30SLD
037-1238941
37-30SLD Bar, Spacer (uses 2) $3.40 More Info
39-30SLD In Stock 39-30SLD
039-1238942☀
39-30SLD Screw (uses 2) $1.15 More Info
39A-30SLD In Stock 39A-30SLD
039A-1258668
39A-30SLD Screw, Self-Tapping Screw (uses 2) $1.15 More Info
41-30SLD In Stock 41-30SLD
041-1238943
41-30SLD Spring $1.15 More Info
50-30SLD In Stock 50-30SLD
050-1238944☀
50-30SLD Shield, Gear Stud $5.00 More Info
52A-260 In Stock 52A-260
052A-1183843☀
52A-260 Screw, Self Tapping Screw (uses 2) $1.15 More Info
53B-5600 In Stock 53B-5600
053B-1183848☀
53B-5600 Spring
Used on multiple models in different quantities.
$1.15 More Info
55-30SLD In Stock 55-30SLD
055-1238945▲
55-30SLD Bearing $5.70 More Info
55A-50SLD In Stock 55A-50SLD
055A-1238912☀
55A-50SLD Bearing, Ball Bearing $10.80 More Info
55T-30SLD In Stock 55T-30SLD
055T-1238913▲
55T-30SLD Bearing Assembly $14.80 More Info
62-TRQ40 In Stock 62-TRQ40
062-1236596☀
62-TRQ40 Spring $1.95 More Info
62A-310 In Stock 62A-310
062A-1184033☀
62A-310 Spring, Click Spring (uses 2)

NEW System on 330GT and 330LD Reels
$1.15 More Info
62B-525 In Stock 62B-525
062B-1184037☀
62B-525 Pin, Click Pin (uses 2) $1.70 More Info
62C-30SLD In Stock 62C-30SLD
062C-1238914
62C-30SLD Plate, Click Retaining $1.35 More Info
62A-TRQ40 In Stock 62A-TRQ40
062A-1230189
62A-TRQ40 Block, Click Button Locator $1.15 More Info
62C-321LH In Stock 62C-321LH
062C-1184041
62C-321LH Cover, Click Spring (uses 2)

NEW System on 330GT and 330LD Reels
$1.15 More Info
66-30SLD In Stock 66-30SLD
066-1238915☀
66-30SLD Ratchet, Click $1.15 More Info
69A-30SLD In Stock 69A-30SLD
069A-1238916
69A-30SLD Ring, Retaining, Round $1.65 More Info
69B-50 In Stock 69B-50
069B-1184125☀
69B-50 Ring, Retaining Ring (E-Clip)
Used on multiple models in different quantities.
$1.15 More Info
69D-30SLD In Stock 69D-30SLD
069D-1238917
69D-30SLD Ring, Retaining, Round $1.65 More Info
71A-30SLD In Stock 71A-30SLD
071A-1238918
71A-30SLD Plate, Spindle Locking Plate $1.50 More Info
71L-30SLD In Stock 71L-30SLD
071L-1238979
71L-30SLD Spindle $11.55 More Info
82-25 Discontinued. Still In Stock. Limit 2 82-25
082-1184220
82-25 Shim, Handle Shim $2.85 More Info
98-30SLD In Stock 98-30SLD
098-1238980
98-30SLD Ratchet $3.00 More Info
110A-30SLD In Stock 110A-30SLD
110A-1238983☀
110A-30SLD Plate, Handle Nut Locking Plate $1.40 More Info
112C-30SLD In Stock 112C-30SLD
112C-1238984
112C-30SLD Pin, Click $1.15 More Info
112E-30SLD In Stock 112E-30SLD
112E-1238985
112E-30SLD Housing Lever Click $1.80 More Info
117-30SLD-1 In Stock 117-30SLD-1
117-1238987
117-30SLD-1 Plate, Drive Plate $9.95 More Info
117A-30SLD In Stock 117A-30SLD
117A-1238990
117A-30SLD Drag Washer, Assembly $22.20 More Info
117W-30SLD In Stock 117W-30SLD
117W-1238993
117W-30SLD Washer, Drag Washer (Metal) $6.45 More Info
117W-40SLD In Stock 117W-40SLD
117W-1239249
117W-40SLD Washer, Drag Washer (Metal) $6.45 More Info
120-30SLD In Stock 120-30SLD
120-1238994☀
120-30SLD O-Ring $1.15 More Info
134-30SLD In Stock 134-30SLD
134-1238995
134-30SLD Gear Stud $13.70 More Info
141-30SLD In Stock 141-30SLD
141-1238996
141-30SLD Follower, Cam $5.05 More Info
144-30SLD In Stock 144-30SLD
144-1238997
144-30SLD Knob, Preset $2.70 More Info
149-45 In Stock 149-45
149-1184702♦
149-45 Nut, Clamp, Long, for Thick Clamps (uses 2)
Used with the graphite clamps 33-114H2, 33-340, 33N-113 and the iron alloy clamp 33i-113
$1.45 More Info
149-200 In Stock 149-200
149-1184706☀
149-200 Nut, Clamp Hex Nut (uses 2) $1.15 More Info
156-30SLD In Stock 156-30SLD
156-1239001
156-30SLD Cover, Drag $4.20 More Info
157-30SLD In Stock 157-30SLD
157-1239002☀
157-30SLD Bushing, Quadrant (uses 2) $2.55 More Info
161-30SLD Backordered. Still In Stock. Limit 5 161-30SLD
161-1239011
161-30SLD Button, Free Spool Button $2.55 More Info
161-40 Backordered. Still In Stock. Limit 5 161-40
161-1184787
161-40 Button, Strike Button $3.00 More Info
162-TRQ40NLD2 In Stock 162-TRQ40NLD2
162-1318280
162-TRQ40NLD2 Spring
Used on multiple models in different quantities.
$1.15 More Info
183-30SLD In Stock 183-30SLD
183-1239012
183-30SLD Frame, Complete Assembly $37.10 More Info
252-30SLD In Stock 252-30SLD
252-1257817
252-30SLD Washer, Thrust (uses 3) $5.65 More Info
252A-30SLD In Stock 252A-30SLD
252A-1257818
252A-30SLD Washer, C'Boro Thrust Washer, $6.35 More Info
253-30SLD In Stock 253-30SLD
253-1257829
253-30SLD Ball and Cage Assembly (uses 2) $1.75 More Info
