Model Specs:

More Info
  • Lightweight graphite frame
  • Machined and anodized aluminum spool
  • Built in linecounter for precise depth control (LC models)
  • High-strength marine grade bronze alloy main gear
  • Precision-machined stainless steel pinion gear
  • HT-100™ drag washers provide smooth drag under heavy loads
  • Stainless steel level wind
  • Counter-balanced handle with oversized paddle knob
  • Stainless steel reel stand
Mono Cap
(yds/lb)
Braid Cap
(yds/lb)
Bearings Max Drag Gear Ratio
410/15
290/20
190/30
775/20
575/30
400/50
2 BB 12 lbs 4.3:1
REEL DISCONTINUED BY PENN

Many of these parts will become unavailable in the future.
Click above for more info

3-320
003-1180726
$30.40
4-349
004-1180775♦
$1.30
5N-320
005N-1180897▲
5N-320 Gear, Main Gear

REPLACES ORIGINAL NUMBER 5-320 ON SOME REELS

$27.40
6-875
006-1180927
6-875 Washer, Drag Washer HT-100™

Can be used as a sub for the 4-349 hard washer under main gear

$0.00
7C-330
007C-330▲
$6.50
8-349
008-1181077☀
8-349 Spring, Tension Spring

113H Fits All Versions.

$1.50
10-349
010-1181197▲
$13.20
11-320
011-1181242☀
$2.40
13N-320
013N-1181380☀
$9.15
14-330
014-1181402☀
$1.30
15-320
015-1181459☀
$1.45
17-113H
017-1181595☀
17-113H Screw, Bridge, Upper Bridge Screw (uses 2)

MULTI USE See Description

113H Fits All Versions.

$1.30
18-60
018-1181615☀
18-60 Spring, Clutch Spring

Used on multiple models in different quantities.

$1.30
19-320
019-1181683☀
$3.30
20-113H2
020-1288917♦
20-113H2 Spring, Eccentric Spring

REPLACES ORIGINAL NUMBER 20-155 and 20-220 ON SOME REELS

$1.30
20-155
020-1181769
20-155 Spring, Eccentric Spring

Used on multiple models in different quantities.
113H Fits All Versions.
Direct product replacement: 20-113H2 Spring, Eccentric Spring $1.30

$0.00
21-209
021-1181855☀
21-209 Lever, Eccentric Lever

REPLACES ORIGINAL NUMBER 21-285 ON SOME REELS


Reels that used 21-285 were: 60,60-LH,65,79,80 (Conv.),85,185 Seaboy,190 Seaboy (1990+),210M,285M, 320GT,320GT2,320GT2LC,321GT2-LH,321GT-LH,350M aka 350,505HS,506HS

$2.55
21-285
021-1181860
$0.00
22-60CH
022-1181908☀
22-60CH Screw, Eccentric Screw with washer (Sems) (Silver)

REPLACES ORIGINAL NUMBER 22-60, 22-113HN ON SOME REELS

114H Fits Half Frame Version.

$2.55
23-114
023-1181945☀
23-114 Screw, Handle Screw, Chrome Fin. (w/ OILER)

MULTI USE See Description

113H Fits All Versions.

$5.50
23M-114
023M-1181961☀
23M-114 Screw, Handle Screw, Matte Fin. with Oiler

MULTI USE See Description

113H Fits All Versions.

$9.85
24-320
024-1182024▭
24-320 Handle, Chromed, Flat Rubberized Knob

FITS: Type [B] Bridge/Sleeve

REPLACES ORIGINAL PART NUMBER 24-970 ON SOME REELS

$25.20
24-330
024-330
24-330 Handle, Ergo Paddle, Black Handle Blank

REPLACED BY PART NUMBER 24S-225

Direct product replacement: 24S-225 Handle, Stainless, Rubberized Football Knob $43.15

$0.00
24S-320
024S-1191343
24S-320 Handle, Stainless, Ergonomic Knob

FITS: Type [B] Bridge/Sleeve

REPLACES ORIGINAL NUMBER 24-970 ON SOME REELS

$0.00
24SN-320
024SN-1191343
24SN-320 Handle, Chromed, Rubberized Football Knob

FITS: Type [B] Bridge/Sleeve

REPLACES ORIGINAL PART NUMBER 24-970 ON SOME REELS

$28.75
26B-320
026B-1182137☀
26B-320 Cap, Spool, Tension Control Cap (CAP ONLY)

REPLACES ORIGINAL NUMBER 26B-310, 26B-330 ON SOME REELS

$3.60
26B-320SP
026B-320SP▲
26B-320SP Spool Tension Control Cap Kit


Four Piece Cap Kit Assembly

$8.90
32-17
032-1182710☀
32-17 Screw

REPLACES ORIGINAL PART NUMBER 32-110 ON SOME REELS

Used on multiple models in different quantities.

$1.30
33-16VS
033-1191592▲
33-16VS Clamp, Rod Clamp with Ring (Thick) (Iron Alloy) (Grey)

REPLACES ORIGINAL NUMBERS 33-16S, 33-TRQS ON SOME REELS

$21.85
33N-113
033N-1182754☘
33N-113 Clamp, Rod Clamp with Side Ring (Thick) (Graphite) (Black)

REPLACES ORIGINAL NUMBER 33-113 ON SOME REELS

$5.90
34-45
034-1182788▲
34-45 Screw, Rod Clamp Screw (Shorter for Thick Clamps) ONLY (uses 2)

This is just the stud

114 Fits Frame Posts Version.
114H Fits Frame Posts Version.

$1.50
34C-45
034C-1182862▲
34C-45 Screw With Nuts, for Thick Style Rod Clamp (uses 2)

114 Fits Frame Posts Version.
114H Fits Frame Posts Version.

$5.85
35-310N
035-1182922☀
35-310N Tongue, Click Tongue


NEW System on 330GT and 330LD Reels

$2.30
36-700
036-1183014☀
36-700 Nut, Locking Nut

REPLACES ORIGINAL NUMBER 36-710 ON SOME REELS

$2.30
36N-320LD
036N-1183049
36N-320LD Button, Click Button

REPLACES ORIGINAL NUMBER 36-320LDON SOME REELS

$3.00
40-320
040-1183280☀
$15.50
40C-320
040C-1183310☀
$1.30
41-330
041-1183336☀
41-330 Spring, Thrust, Handle Side Thrust Spring

REPLACES ORIGINAL NUMBER 41-320 ON SOME REELS

$1.30
42-320N
042-1183350▲
$11.00
43-330
043-1183384☀
43-330 Bearing, Worm, Handle Side

REPLACES ORIGINAL PART NUMBER 43-320 ON SOME REELS

$1.90
44-320
044-44-320
44-320 Bearing, Worm Bearing, Non-Handle Side


For Use with Original 50-320 Worm Shield

REPLACED BY PART NUMBER 44-330

$0.00
44-330
044-1183446☀
44-330 Bearing, Worm, Non-Handle Side

REPLACES ORIGINAL PART NUMBER 44-320 ON SOME REELS

MULTI USE See Description

$1.80
46-320N
046-1183562▲
$11.00
47-975
047-1183677♦
47-975 Pawl, Line Guide Pawl

REPLACES ORIGINAL PART NUMBER 47-320 ON SOME REELS

$3.00
50T-320
050T-1191972☀
50T-320 Shield, Worm Shield

REPLACES ORIGINAL NUMBER 50N-320 and 50-320 ON SOME REELS

$5.20
58-320
058-1183954☀
$2.60
62A-310
062A-1184033☀
62A-310 Spring, Click Spring (uses 2)


NEW System on 330GT and 330LD Reels

$1.30
62C-321LH
062C-1184041★
62C-321LH Cover, Click Spring (uses 2)


NEW System on 330GT and 330LD Reels

$1.30
62S-310
062S-1192075☀
62S-310 Pin, Click Pin (uses 2)


NEW System on 330GT and 330LD Reels

REPLACES ORIGINAL NUMBER 62B-310 ON SOME REELS

$1.50
63-500S
063-1184052☀
63-500S Screw

MULTI USE See Description

Used on multiple models in different quantities.

$1.35
64-320
064-1184066☀
$4.10
67-9
067-1184102☀
$1.30
69B-600
069B-1184129♦
69B-600 | DSS-VP2041 Ring, Retaining Ring (E-clip)

Used on multiple models in different quantities.

$1.50
98-320
098-1184349▲
$18.30
Custom Sleeves Replacing: 98-320

Stainless Steel Gear Sleeves by other manufacturers. Click link to view options.

102-113H
102-113H
$0.00
110-50
110-1184436☀
110-50 Screw

Used on multiple models in different quantities.

$1.30
110-60
110-1184437♦
110-60 Screw, Handle Lock Screw

REPLACES ORIGINAL PART NUMBER 23A-60 ON SOME REELS

$1.30
154-117
154-1184721☀
154-117 Washer or Shim


NEW System on 330GT and 330LD Reels

$1.35
183-320GT2
183-1184911
$38.25
168-115
168-1184804☘
168-115 Wrench

FITS 23-50S, 23-114, 23M-114, 23-116, 23-220, 23-FTH20LW, 23-16S, 23-60 knurled nuts

$1.30
PEN XXSMRC
1178860
XXSMRC Cover, Reel Cover, Conventional, Size Extra-Extra Small

FITS REELS:
9M, 109M, 209M
110, 111, 112, 112H, 112H2
140L, 145, 146L, 220
310GT, 310GTi, 310GT2, 320GT, 320GTi, 320GT2, 320LD
500L, 501, 525, 525GS, 525MAG, 535, 535GS, 545, 545GS, 555, 555GS
965, 975, 975CS, 975CSLD, 975SLD
DFN20LW, DFN25LW, DFN30
FTH12, FTH15, FTH15LD2, FTH15LD, FTH15LW, FTH20LW, FTH25N, FTH25NLD, FTH25NLD2, FTH25LW, FTH30, FTH30LD, FTH30LD2, FTH30LD2LH, FTH25NLD2, FTH30LD, FTH40
SQL200LP, SQL200LPLH,SQL200LPHS,SQL300LP, SQL300LPLH,SQL300LPHS,SQL400LP, SQL400LPLH,SQL400LPHS
SQL12, SQL15, SQL15LW, SQL20LW, SQL25N
SQLii12SD, SQLii15SD, SQLii15SDCS, SQLii25NSD
TRQ15LD2, TRQ25NLD2, TRQ30LD2, TRQ12, TRQ15, TRQ25, TRQ30, TRQ40, TRQ100, TRQ100LD, TRQ200
WAR15LW, WAR15LWLH

$0.00
149-45
149-1184702♦
149-45 Nut, Clamp, Long, for Thick Clamps (uses 2)

Used with the graphite clamps 33-340, 33N-113, aluminum 33-TRQ, 33-TRQS and iron alloy clamp 33i-113 and 33-16VS

$1.60
