Model Specs:

More Info
  • Machined and anodized aluminum body and sideplates
  • Stainless steel main and pinion gears
  • Quick-Shift II™ 2-speed system
  • Dura-Drag™ system
  • Versa-Strike Adjustable Strike stop
  • Double-dog ratchet anti-reverse
  • Line Capacity Rings
  • Made in the USA of domestic and imported components
Mono Cap
(yds/lb)
Braid Cap
(yds/lb)
Bearings Max Drag Gear Ratio Line Retrieve
1510/10
1030/12
880/15
985/40
840/50
700/65
5 15lbs 6.75:1 53
Availability SKU Name Our Price
Work in Progress Backordered. Not Available Work in Progress Work in Progress
MysticParts.com in the process of updating this page with parts and schematics.
$0.00 More Info
1-12VIG In Stock 1-12VIG
1364733
1-12VIG Plate, Right Handle Side Plate Assembly (Gold) $347.25 More Info
1D-12VIG  In Stock 1D-12VIG
1364735
1D-12VIG Cover, Gear Cover (Gold) $7.65 More Info
2-12VI In Stock 2-12VI
1364736
2-12VI Ring, Quadrant Ring $5.05 More Info
2A-12VI In Stock 2A-12VI
1364737
2A-12VI Spacer, Quadrant Spacer $2.35 More Info
2B-50VIS In Stock 2B-50VIS
1361403
2B-50VIS Stop, Strike Stop $1.50 More Info
2C-50VIS In Stock 2C-50VIS
1361404
2C-50VIS Indictator, Strike Indicator $7.40 More Info
3C-16VIS In Stock 3C-16VIS
1423887
3C-16VIS Plate, Dog Retaining Plate $0.95 More Info
4-12VI In Stock 4-12VI
1364749
4-12VI Washer, Drag Lever Washer $0.95 More Info
5-12VI  In Stock 5-12VI
1364750
5-12VI Gear, Main Gear $45.70 More Info
7A-12V In Stock 7A-12V
1364756
7A-12VI Washer, Metal Drag Washer $14.00 More Info
13-12VI In Stock 13-12VI
1364759
13-12VI Gear, Pinion Gear $35.30 More Info
13A-12VI In Stock 13A-12VI
1365543
13A-12VI Tube, Spool Spacer Tube $2.65 More Info
13B-12V In Stock 13B-12V
1364763
13B-12V Spacer, Spool Spacer (uses 2)
Same as 13B-12VI
$0.95 More Info
14-535 In Stock 14-535
1181406
14-535 Spring
Used on multiple models in different quantities.
$0.70 More Info
15-16VIS In Stock 15-16VIS
1443478
15-16VIS Dog (uses 2) $1.40 More Info
17-975LD In Stock 17-975LD
1181604
17-975LD Screw, Long Bridge Screw
Used on multiple models in different quantities.
$0.55 More Info
18-TRQ40NLD2 In Stock 18-TRQ40NLD2
1265001
18-TRQ40NLD2 Washer, Spring Washer (uses 2) $0.80 More Info
18C-15KG In Stock 18C-15KG
1181632
18C-15KG Spring
(Also part of 170-130VS, 124L-30VS, 124L-16VS, 124L-50VS assemblies)
Used on multiple models in different quantities.
$0.85 More Info
19-12VI In Stock 19-12VI
1364764
19-12VI Cam, Drag Cam $12.10 More Info
21-12VIG In Stock 21-12VIG
1364765
21-12VIG Lever, Drag Lever Asm (Gold) $92.00 More Info
21A-50VIS In Stock 21A-50VIS
1361392
21A-50VIS Guide, Drag Lever Guide
Used on multiple models in different quantities.
$0.95 More Info
23-12VI In Stock 23-12VI
1364767
23-12VI Screw, Handle Screw $7.10 More Info
24-12VI In Stock 24-12VI
1364768
24-12VI Handle Assembly $28.75 More Info
24-12VI-1 Backordered. Not Available 24-12VI-1
1364769
24-12VI-1 Arm, Handle Arm More Info
24C-113HN In Stock 24C-113HN
1182092
24C-113HN Cap ONLY, Handle Knob Cap, Chromed Tin
For football-shaped handle knob
$3.85 More Info
25S-113HN In Stock 25S-113HN
1207739
25S-113HN Knob, Handle $7.05 More Info
26-16VIS In Stock 26-16VIS
1364772
26-16VIS Bearing, Spool Ball Bearing $4.05 More Info
26NS-25 In Stock 26NS-25
1435256
26NS-25 Bearing, Ball Bearing (Right Side) $5.75 More Info
27-12VIG In Stock 27-12VIG
1364774
27-12VIG Plate, Non-Handle Side Plate (Gold) $137.45 More Info
29-12VIG In Stock 29-12VIG
1364776
29-12VIG Spool (Gold) $65.55 More Info
30-16VS In Stock 30-16VS
1182599
30-16VS Stand $19.30 More Info
31-16VS In Stock 31-16VS
1191562
31-16VS Screw, Stand (uses 4) $1.55 More Info
31-50VIS In Stock 31-50VIS
1361407
31-50VIS Screw, Center Quadrant Screw $0.95 More Info
33-16VS In Stock 33-16VS
1191592
33-16VS Clamp, Rod Clamp with Ring (Thick) (Iron Alloy) (Grey)

REPLACES ORIGINAL NUMBERS 33-16S, 33-TRQS ON SOME REELS

$16.55 More Info
33-TRQ In Stock 33-TRQ
1290729
33-TRQ Clamp, Rod Clamp (Thick) (Aluminum) (Black) $1.25 More Info
33-TRQS Backordered. New Item Not Yet Stocked 33-TRQS
1365544
33-TRQS Clamp, Rod Clamp (Thick) (Aluminum) (Silver) More Info
33C-12VIS In Stock 33C-12VIS
1457209
33C-12VIS Rod Clamp Kit Clamp/Studs/Nuts $11.50 More Info
34-16VS In Stock 34-16VS
1182786
34-16VS Screw ONLY, for Rod Clamp (uses 2) $4.15 More Info
35-12VI In Stock 35-12VI
1364777
35-12VI Tongue, Click Tongue $0.95 More Info
36-12VI In Stock 36-12VI
1364778
36-12VI Button, Click Button $5.40 More Info
36A-FTH40NLD2 In Stock 36A-FTH40NLD2
1309883
36A-FTH40NLD2 Click Washer $0.70 More Info
36B-12VI In Stock 36B-12VI
1365545
36B-12VI Spacer, Click Spacer $0.95 More Info
36B-FTH20LW In Stock 36B-FTH20LW
1188651
36B-FTH20LW Washer, Click, PVC Click Washer $0.95 More Info
36C-12VI In Stock 36C-12VI
1364779
36C-12VI Click Sub Assembly $27.50 More Info
39-12VIN In Stock 39-12VIN
1364781
39-12VIN Screw with Collar (uses 7) $1.15 More Info
39-12VSX In Stock 39-12VSX
1229975
39-12VSX Screw, Plate, Both Sides (uses 2)

REPLACES ORIGINAL NUMBER 38-965 ON SOME REELS

$0.80 More Info
39-50VIS In Stock 39-50VIS
1361411
39-50VIS Screw
Used on multiple models in different quantities.
$0.95 More Info
41-12VI In Stock 41-12VI
1364782
41-12VI Spring, Left Side Spool Spring $1.35 More Info
41A-12VI In Stock 41A-12VI
1364783
41A-12VI Spring, Drag Spring (Wave) $4.50 More Info
41B-12VI In Stock 41B-12VI
1364784
41B-12VI Spring, Drive Plate Separating Spring $3.50 More Info
46A-4300 In Stock 46A-4300
1183585
46A-4300 Screw, Short
Used on multiple models in different quantities.
$0.60 More Info
50-12VI In Stock 50-12VI
1364785
50-12VI Shield, Gear Stud Shield $9.95 More Info
53A-5600 In Stock 53A-5600
1183846
53A-5600 Pin
Used on multiple models in different quantities.
$0.85 More Info
55A-50SLD In Stock 55A-50SLD
1238912
55A-50SLD Bearing, Ball Bearing $5.25 More Info
55L-FTH20LD2 In Stock 55L-FTH20LD2
1286985
55L-FTH20LD2 Bearing, Ball Bearing (uses 2) $12.50 More Info
62-12VI In Stock 62-12VI
1364787
62-12VI Spring, Click Spring $1.70 More Info
62A-12VI In Stock 62A-12VI
1364788
62A-12VI Click Spring Tongue (uses 2) $4.80 More Info
63-12VI In Stock 63-12VI
1364790
63-12VI Screw Click Mount (uses 3) $0.95 More Info
63A-12VS In Stock 63A-12VS
1233968
63A-12VS Screw, Rivet, Handle
Used on multiple models in different quantities.
$1.35 More Info
63B-16VIS In Stock 63B-16VIS
1354421
63B-16VIS Washer, Handle Screw Washer $1.65 More Info
63D-16VIS In Stock 63D-16VIS
1454102
63D-16VIS Washer, Handle Rivet Washer $0.95 More Info
66-12VI In Stock 66-12VI
1364791
66-12VI Ratchet, Spool Click Ratchet $0.95 More Info
69-FTH20LW In Stock 69-FTH20LW
1188657
69-FTH20LW Retainer (E-clip)
Used on multiple models in different quantities.
$0.55 More Info
71-12VI In Stock 71-12VI
1364792
71-12VI Spindle $105.00 More Info
91-12VI In Stock 91-12VI
1454103
91-12VI Rivet, Handle Rivet $10.05 More Info
95-12VI In Stock 95-12VI
1364795
95-12VI Click Housing $1.70 More Info
98-12VI In Stock 98-12VI
1364796
98-12VI Ratchet, Anti-Reverse Ratchet $1.50 More Info
110-50 In Stock 110-50
1184436
110-50 Screw
Used on multiple models in different quantities.
$0.70 More Info
110A-50 In Stock 110A-50
1184441
110A-50 Plate, Locking, Handle Locking Plate $3.45 More Info
112-50VIS In Stock 112-50VIS
1361351
112-50VIS Button, Strike Button $3.45 More Info
112A-50VIS In Stock 112A-50VIS
1361352
112A-50VIS Gate, Strike Gate $0.95 More Info
112B-50VIS In Stock 112B-50VIS
1361353
112B-50VIS Spring, Strike-Button Spring $0.95 More Info
117-12VI In Stock 117-12VI
1364798
117-12VI Outer Drive Plate Assembly $16.55 More Info
117A-12VI In Stock 117A-12VI
1364800
117A-12VI Inner Drive Plate Assembly $15.90 More Info
117S-TRQ40NLD2 In Stock 117S-TRQ40NLD2
1265080
117S-TRQ40NLD2 Seal, Drag Cover Seal $4.20 More Info
128-12VI In Stock 128-12VI
1364802
128-12VI Pin, Gear Stud Drive Pin $1.50 More Info
134-12VI In Stock 134-12VI
1364803
134-12VI Stud, Gear Stud $21.90 More Info
134A-30SLD2 In Stock 134A-30SLD2
1265086
134A-30SLD2 Nut, Gear Stud Nut $2.70 More Info
141-TRQ15LD2 In Stock 141-TRQ15LD2
1265088
141-TRQ15LD2 Cam Follower $8.50 More Info
141B-TRQ15LD2 In Stock 141B-TRQ15LD2
1265089
141B-TRQ15LD2 Spring, Preset Knob Spring $0.75 More Info
144-12VI In Stock 144-12VI
1364804
144-12VI Knob, Preset Knob $9.60 More Info
149-45 In Stock 149-45
1184702
149-45 Nut, Clamp, Long, for Thick Clamps (uses 2)
Used with the graphite clamps 33-114H2, 33-340, 33N-113 and the iron alloy clamp 33i-113
$1.10 More Info
149-200 In Stock 149-200
1184706
149-200 Nut, Clamp Hex Nut (uses 2) $0.60 More Info
154B-FTH25NLD2 In Stock 154B-FTH25NLD2
1309903
154B-FTH25NLD2 Belleville Distance Washer
Used on multiple models in different quantities.
$1.40 More Info
154B-FTH40NLD2 In Stock 154B-FTH40NLD2
1309904
154B-FTH40NLD2 Distance Washer (as required) $1.40 More Info
156-12VI In Stock 156-12VI
1364805
156-12VI Cover, Drag Cover $1.85 More Info
158-50VIS In Stock 158-50VIS
1361374
158-50VIS Pin, Dog Pin (uses 2) $0.95 More Info
161A-TRQ15LD2 In Stock 161A-TRQ15LD2
1265098
161A-TRQ15LD2 Pin, Lever Click Pin $0.75 More Info
183-12VIG In Stock 183-12VIG
1364807
183-12VIG Frame (Gold) $103.10 More Info
183A-12VIG In Stock 183A-12VIG
1364809
183A-12VIG Extension, Frame Extension (Gold) $19.80 More Info
195-40 In Stock 195-40
1184955
195-40 Retaining "E" Ring
Used on multiple models in different quantities.
$1.10 More Info
302-12VI In Stock 302-12VI
1364810
302-12VI Slider, Adjustable Click Slider $1.50 More Info
302B-525MAG2 In Stock 302B-525MAG2
1214682
302B-525MAG2 Brake Adjustment Dial $1.10 More Info
302C-12VI Backordered. Not Available 302C-12VI
1364811
302C-12VI Plate, Click Cover Plate More Info
302H-525MAG2 In Stock 302H-525MAG2
1214685
302H-525MAG2 Screw $0.60 More Info
168-INTVI  In Stock 168-INTVI
1410723
168-INTVI Multi-Tool for the new International VI series reels
partimage
$15.65 More Info
