Model Specs:

More Info
  • Machined gold anodized aluminum skirted spools, with handy line capacity chart.
  • Shielded stainless steel ball bearings for easy reeling and top performance.
  • Naval brass or stainless-steel pinion gear.
  • Naval brass or high quality machined anodized marine aluminum main gear.
  • Powerful gears machined from the highest grade metals.
  • Smooth, dependable drag system.
  • Stainless steel, hard chrome plated line rollers, with bushing underneath to ensure constant rolling for minimum line wear.
  • Housing and rotor cups are anodized die cast aluminum and feature a durable, baked enamel.
  • Sideplates and bail arms are graphite composites for a combination of lightest weight and strength.
  • Stainless steel bail, featuring an internal trip.
  • Anti-reverse is silent.
  • Drag knob featuring a push button to remove the spool.
  • Right or left hand drive (requiring change of pivot) on a convertible handle which folds easily.
  • 650SS to 950SS: An additional lever is located under the rotor cup that permits a slient or click option while reel is in anti-reverse.
Mono Cap
(yds/lb)
Braid Cap
(yds/lb)
Bearings Gear Ratio
185/2
150/4
120/6
180/6
150/8
130/10
3 5.3:1
Availability SKU Name Our Price
REEL DISCONTINUED BY PENN   REEL DISCONTINUED BY PENN

Many of these parts will become unavailable in the future.
Click above for more info

1-420 Discontinued. Still In Stock. Limit 1 1-420
001-1180505
1-420 Housing with Bushing

LIMITED QUANTITIES AVAILABLE

$23.20 More Info
2-420 Discontinued. Not Available 2-420
002-1180644
2-420 Brass Housing Handle Bushing (uses 2) More Info
4-420 Discontinued. Not Available 4-420
004-1180776
4-420 Anti-Reverse Dog More Info
6A-716 Discontinued. Still In Stock. Limit 2 6A-716
006A-1180957
6A-716 Eccentric $6.15 More Info
6B-700Z In Stock 6B-700Z
006B-1180965☀
6B-700Z Liner, Silent Eccentric Liner $2.00 More Info
6D-716 Discontinued. Not Available 6D-716
006D-1180978
6D-716 Spring, Eccentric Spring More Info
6E-716 Discontinued. Still In Stock. Limit 2 6E-716
006E-1180986☀
6E-716 Lever, Eccentric Lever $3.50 More Info
7-716 Discontinued. Still In Stock. Limit 2 7-716
007-1181022☀
7-716 Bushing, Pinion $1.25 More Info
8-420 Discontinued. Not Available 8-420
008-8-420
8-420 Gear, Main Gear Ratchet & Shaft More Info
13-716 Discontinued. Still In Stock. Limit 5 13-716
013-1181355☀
13-716 Screw, Crosswind Screw $1.90 More Info
14-716 In Stock 14-716
014-1181410☀
14-716 Roller, Crosswind Roller $1.15 More Info
15-716 Discontinued. Not Available 15-716
015-15-716
15-716 Handle, Gold, Hard Plastic Knob More Info
15-716Z Discontinued. Not Available 15-716Z
015-15-716Z
15-716Z Handle, Gold, Rubberized Knob More Info
17-716 Discontinued. Not Available 17-716
017-1181602
17-716 Handle Washer More Info
19-420 Discontinued. Still In Stock. Limit 2 19-420
019-1191236☀
19-420 Gear, Stainless Pinion Gear $12.30 More Info
19-716 Discontinued. Still In Stock. Limit 2 19-716
019-1181711☀
19-716 Gear, Pinion Gear $12.30 More Info
20-722 In Stock 20-722
020-1181792☀
20-722 Bearing, Ball Bearing
Used on multiple models in different quantities.
$13.30 More Info
21-722 In Stock 21-722
021-1181879☀
21-722 Retainer, U Shaped Bearing Retainer $1.15 More Info
22-109 In Stock 22-109
022-1181912☀
22-109 Screw (SEMS 540 x 156)

MULTI USE See Description

Used on multiple models in different quantities.
$1.70 More Info
24-420 Discontinued. Still In Stock. Limit 2 24-420
024-1182032
24-420 Bail Wire $12.55 More Info
27-420 In Stock 27-420
027-1182235
27-420 Rotor Cup $17.10 More Info
27A-420 In Stock 27A-420
027A-1182318
27A-420 Cover, Bail Trip Cover

LIMITED QUANTITIES AVAILABLE

$1.70 More Info
27B-420 In Stock 27B-420
027B-1182338☀
27B-420 Screw

MULTI USE See Description

$1.15 More Info
27C-420 Discontinued. Not Available 27C-420
027C-420
27C-420 Cover, Trip Lever Cover More Info
28-420 In Stock 28-420
028-1182393☀
28-420 Lever, Trip Lever $1.60 More Info
28A-450 Discontinued. Still In Stock. Limit 2 28A-450
028A-1182427☀
28A-450 Lever, Cam Lever $2.55 More Info
28C-420 In Stock 28C-420
028C-1182449☀
28C-420 Cam, Trip Cam $1.70 More Info
31-420 Discontinued. Not Available 31-420
031-1182668
31-420 Screw, Bail Arm Screw More Info
31A-420 Discontinued. Still In Stock. Limit 2 31A-420
031A-1182687
31A-420 Screw, Bail Cam Screw, Chrome $5.55 More Info
32-420 In Stock 32-420
032-1182725☀
32-420 Spring, Bail Spring $1.15 More Info
34-420 In Stock 34-420
034-1182818▲
34-420 Arm, Bail Arm $4.05 More Info
35-420 In Stock 35-420
035-1182926☀
35-420 Line Roller $6.70 More Info
36-420 Discontinued. Not Available 36-420
036-1183006
36-420 Screw, Bail Stud Screw
36-750 Screw $1.15
More Info
36A-750 In Stock 36A-750
036A-1183032☀
36A-750 Washer, Lock Washer

REPLACES ORIGINAL PART NUMBER 233A-1000AF ON SOME REELS

$1.15 More Info
37-420 In Stock 37-420
037-1183076
37-420 Washer, Rotor Cup Washer $1.15 More Info
38-720 In Stock 38-720
038-1183158☀
38-720 Nut, Rotor Cup Nut $1.15 More Info
39-420 Discontinued. Not Available 39-420
039-1183214
39-420 Shaft, Spool Shaft More Info
40-716 Discontinued. Not Available 40-716
040-1183283
40-716 Sleeve, Spool Sleeve More Info
43-716 Discontinued. Not Available 43-716
043-1183403
43-716 Arm, Crosswind Arm More Info
44-716 In Stock 44-716
044-1183460☀
44-716 Screw, Crosswind Shaft Screw $1.15 More Info
45-420SS Discontinued. Not Available 45-420SS
045-1183499
45-420 Cover, Housing Cover More Info
46-716 Discontinued. Still In Stock. Limit 5 46-716
046-1183574☀
46-716 Screw, Housing Cover Screw $1.25 More Info
46A-704 In Stock 46A-704
046A-1183586☀
46A-704 Screw (Pan Head)

MULTI USE See Description

$1.15 More Info
47-420 Discontinued. Not Available 47-420
047-1183631
47-420 Spool (Inc. Drags/Clicker, Drag Knob) More Info
48-420 Discontinued. Still In Stock. Limit 2 48-420
048-1183706
48-420 Spring, Click Spring $2.00 More Info
50-420 In Stock 50-420
050-1183764
50-420 Screw, Click Spring Screw $1.15 More Info
50-712 In Stock 50-712
050-1183766☀
50-712 Screw
Used on multiple models in different quantities.
$1.15 More Info
50-716 In Stock 50-716
050-1183767☀
50-716 Screw
Used on multiple models in different quantities.
$1.15 More Info
52-716Z Discontinued. Not Available 52-716Z
052-1183835
52-716Z Knob, Drag Knob More Info
54-716 Discontinued. Still In Stock. Limit 5 54-716
054-1183864☀
54-716 Spring, Drag Spring $4.45 More Info
056-420SP Discontinued. Not Available 056-420SP
056-420SP
56-420SP Kit, Drag Washers Complete Kit (3 pcs) More Info
56T-716 Discontinued. Not Available 56T-716
056T-1183921
56T-716 Washer, Drag Washer (Teflon) More Info
57-716 In Stock 57-716
057-1183939☀
57-716 Washer, Keyed Drag Washer (Metal) $1.35 More Info
60-716 In Stock 60-716
060-1184006☀
60-716 Washer, Teflon Thrust Washer $1.15 More Info
62A-716 Discontinued. Not Available 62A-716
062A-1184034
62A-716 Screw More Info
95B-420 In Stock 95B-420
095B-1235666
95B-420 Retaining Plate $2.35 More Info
106-450 Discontinued. Not Available 106-450
106-450
106-450 Spring, Lever Spring

REPLACED BY PART NUMBER 106-5500

More Info
106-5500 In Stock 106-5500
106-1184432☀
106-5500 Spring, Lever Spring

REPLACES ORIGINAL NUMBER 106-450 ON SOME REELS

$1.60 More Info
132-420 Discontinued. Still In Stock. Limit 1 132-420
132-1184585☀
132-420 Washer, Line Roller Washer $3.05 More Info
227-420 Discontinued. Still In Stock. Limit 2 227-420
227-1185043
227-420 Cover, Bail Spring Cover

LIMITED QUANTITIES AVAILABLE

$1.15 More Info
237-420 Discontinued. Not Available 237-420
237-420
237-420 Housing Emblem/Decal "Penn 420ss" More Info
238-420 Discontinued. Not Available 238-420
238-238-420
238-420 Decal, Side Plate (Reel Speed) More Info
240-420 Discontinued. Not Available 240-420 240-420 Decal, Spool (Line Capacity) More Info
