Model Specs:

More Info
  • Lightweight graphite frame
  • Machined and anodized aluminum spool
  • Precision-machined stainless steel pinion gear
  • High-strength marine grade bronze alloy main gear
  • Stainless steel frame rings enhances rigidity to prevent "frame-flex"
  • HT-100™ drag washers provide smooth drag under heavy loads
  • Multi-disc star drag system for smooth and consistent drag
  • 2 shielded stainless steel ball bearings
  • Stainless steel reel stand
  • Convertible power handle
  • Heavy-duty clicker
Mono Cap
(yds/lb)
Braid Cap
(yds/lb)
Bearings Max Drag Gear Ratio Line Retrieve
450/50
390/60
290/80
1250/65
1075/80
925/100
2 22 lbs 2.9:1 28
Availability SKU Name Our Price
1-114H2 In Stock 1-114H2
001-1197483
1-114H2 Plate, Handle Side Plate

$17.55 More Info
2-114H2-i In Stock 2-114H2-i
002-1197490
2-114H2-i Ring, Inner Side Ring (uses 2) $9.50 More Info
2N-114 In Stock 2N-114
002N-1180665
2N-114 Ring, Side Ring, Outer (5 holes)
Used on multiple models in different quantities.
114 Fits Both Half Frames and Full Frame Versions.
114H Fits Full Frame Version.
$11.30 More Info
2N-114H In Stock 2N-114H
002N-1180666
2N-114H Ring, Outer Handle Side Ring (5 holes)
114H Fits Half Frame and Full Frame Versions.
$11.65 More Info
3-114H2 In Stock 3-114H2
003-1197499
3-114H2 Bridge Assembly with Sleeve $23.80 More Info
3-114H-1 Discontinued. Not Available 3-114H-1
003-1197500
3-114H-1 Bridge Sub-Assembly ONLY More Info
4-115 In Stock 4-115
004-1180766☀
4-115 Washer, Hard Fiber Spacer Washer (Under Main Gear)
Used on multiple models in different quantities.
114H Fits All Versions.
$2.10 More Info
P316114H325 Backordered. Still In Stock. Limit 1 P316114H325
P316114H325▲
P316114H325 Custom Stainless Steel 3.25:1 High Speed Gear Set (Optional) $79.04 More Info
5-115 Backordered. Not Available 5-115
005-1180848▲
5-115 Gear, Main Gear
114H Fits All Versions.
More Info
6-114HSD In Stock 6-114HSD
006-114HSD▲
6-114HSD Set, Drag Washers, CARBONTEX by SmoothDrag (Custom) $19.00 More Info
6-114HSP In Stock 6-114HSP
006SP-1180391◉▭
6-114HSP Kit, Drag Washers, Drag Washer Kit HT-100™ with Metals (10 pcs) $16.65 More Info
UU-PENN114H In Stock UU-PENN114H
UU-PENN114H▲
UU-PENN114H 7+1 Drag Washer System (Custom)
Fits: 114H, 114H-LH, 114HL, 114HLW, 115L, 115L-LH
$44.00 More Info
6-115 In Stock 6-115
006-1180911◉
6-115 Washer, Drag Washer HT-100™

REPLACES ORIGINAL NUMBER 6-990 ON THE 990 REEL

$3.45 More Info
7-115 In Stock 7-115
007-1181011
7-115 Washer, Drag, Metal, Round Eared Metal Drag Washer ONLY (uses 2)
114H Fits All Versions.
$1.50 More Info
7C-115 In Stock 7C-115
007C-1181044▲
7C-115 Washer, Drag, Metal Drag Washers (SET of 5)
114H Fits All Versions.
$11.20 More Info
7C-114HSD-5 In Stock 7C-114HSD-5
007C-114HSD-5
7C-114HSD-5 Set, Metal Drag Washers by SmoothDrag (Custom) $14.00 More Info
8-114 In Stock 8-114
008-1181067☀
8-114 Spring, Tension Spring (Belleville)
114H Fits All Versions.
$1.60 More Info
8-115 In Stock 8-115
008-1181068☀
8-115 Spring, Tension Spring (Thick) (Belleville) $1.70 More Info
9-114H Discontinued. Not Available 9-114H
009-1181153
9-114H Sleeve, Spacing Sleeve
114H Fits All Versions.
More Info
10-114 In Stock 10-114
010-1181185▲
10-114 Star Drag Wheel
114 Fits All Versions.
$7.50 More Info
10-114 In Stock 10-114
010-PC10-114
10-114 Star Drag Wheel, Aluminum (CUSTOM)
114 Fits All Versions.
$24.99 More Info
11-114 In Stock 11-114
011-1181234☀
11-114 Jack, Eccentric Jack (Brass)
114 Fits All Versions.
114H Fits All Versions.
$3.70 More Info
12-114 In Stock 12-114
012-1181262☀
12-114 Yoke, Pinion Yoke (Brass)
114 Fits All Versions.
114H Fits All Versions.
$2.55 More Info
12-114SS In Stock 12-114SS
012-114SS▲
12-114SS Yoke, Pinion Yoke (Stainless Steel, CUSTOM)
**For use with stainless gear set.
114 Fits All Versions.
114H Fits All Versions.
$4.50 More Info
13-114H In Stock 13-114H
013-1181322☀
13-114H Gear, Pinion Gear

MULTI USE See Description

$14.35 More Info
14-114 In Stock 14-114
014-1181395☀
14-114 Spring, Dog Spring $1.15 More Info
15-114H In Stock 15-114H
015-1181438☀
15-114H Dog
114H Fits All Versions.
$1.60 More Info
15-114HSS In Stock 15-114HSS
015-114HSS▲
15-114HSS Dog, Stainless Steel (Custom)
114H Fits All Versions.
$4.55 More Info
16-114 In Stock 16-114
016-1181572☀
16-114 Screw, Lower Bridge Screw (uses 2) $1.15 More Info
17-114 In Stock 17-114
017-1181596☀
17-114 Screw, Upper Bridge Screw (uses 2)
114 Fits All Versions.
$1.15 More Info
18-114 In Stock 18-114
018-1181618☀
18-114 Spring, Coiled

MULTI USE See Description

114 Fits All Versions.
$1.15 More Info
18-114H In Stock 18-114H
018-1181619☀
18-114H Spring Disc $1.65 More Info
19-114 In Stock 19-114
019-1181664
19-114 Eccentric
114 Fits All Versions.
$5.55 More Info
20-114 In Stock 20-114
020-1181766☀
20-114 Spring, Eccentric Spring
114 Fits All Versions.
114H Fits All Versions.
$3.30 More Info
21-114 Backordered. Still In Stock. Limit 5 21-114
021-1181845☀
21-114 Lever, Eccentric Lever
114 Fits All Versions.
114H Fits All Versions.
$5.00 More Info
22-114H2 In Stock 22-114H2
022-1197514☀
22-114H2 Screw, Eccentric Screw $1.95 More Info
23-114H2 Backordered. Still In Stock 23-114H2
023-1197515☀
23-114H2 Nut, Handle $5.00 More Info
24-114H2 In Stock 24-114H2
024-1197519
24-114H2 Handle, Chrome, Black Ergo Plastic Knob
FITS: Type [T] Bridge/Sleeve
$27.75 More Info
27-114H2 In Stock 27-114H2
027-1197523
27-114H2 Plate, Non-Handle Side Plate $47.55 More Info
29-114H2 In Stock 29-114H2
029-1191518
29-114H2 Spool, Aluminum (Black) $43.20 More Info
29-114H2SP Backordered. Not Available 29-114H2SP
029-1191519
29-114H2SP Spool, Chrome on Bronze (for Wire Lining) $88.50 More Info
31-2.5FR In Stock 31-2.5FR
031-1182662☀
31-2.5FR Screw

MULTI USE See Description

$1.15 More Info
33-114H2 In Stock 33-114H2
033-1197532☘
33-114H2 Clamp, Rod Clamp, Graphite with ring
Same As: 33N-340 (New 33-340 with Overboard Ring)
114 Fits All Versions.
114H Fits All Versions.
$12.55 More Info
33C-114H2 In Stock 33C-114H2
033C-1197534▭
33C-114H2 KIT Clamp, Rod Clamp, Graphite with ring, with nuts and studs $14.05 More Info
33-114 In Stock 33-114
033-1182755▲
33-114 Rod Clamp, Metal

MULTI USE See Description

Does not fit 30T reel.
114 Fits Frame Posts Version.
114H Fits Frame Posts Version.
$7.15 More Info
33R-114 In Stock 33R-114
033R-1182779▲
33R-114 Ringed Rod Clamp, Metal (Made in China, Brushed Stainless)
Does not fit 30T reel.

See Description

Used on multiple models in different quantities.
114 Fits Frame Posts Version.
114H Fits Frame Posts Version.
$13.25 More Info
34-16VS In Stock 34-16VS
034-1182786▲
34-16VS Screw ONLY, for Rod Clamp (uses 2) $5.00 More Info
35-114 In Stock 35-114
035-1182915☀
35-114 Tongue, Click Tongue

MULTI USE See Description

$1.60 More Info
36-114H Backordered. Still In Stock. Limit 10 36-114H
036-1182991☀
36-114H Button, Click Button

REPLACES PART NUMBER 36-114

$2.25 More Info
37M-114 Discontinued. Not Available 37M-114
037M-1191722
37M-114 Post, for Half Frame, Thin More Info
39-10 Discontinued. Not Available 39-10
039-1183183
39-10 Screw, Short, Pan Head, Die Point (.303 in. overall, thread .215 in. long) More Info
39-12 In Stock 39-12
039-1183184♦
39-12 Screw
Used on multiple models in different quantities.
$1.15 More Info
40-114H2 In Stock 40-114H2
040-1191766☀
40-114H2 Bearing, Non-Handle Side Bearing Assembly $12.55 More Info
54-114 In Stock 54-114
054-1183857☀
54-114 Lug, Harness Lug, Thin (uses 2)

MULTI USE See Description

Used on multiple models in different quantities.
$2.35 More Info
55-116 In Stock 55-116
055-1183882▲
55-116 Bearing, Ball Bearing

MULTI USE See Description

$10.95 More Info
62-114H2 In Stock 62-114H2
062-1197546▲
62-114H2 Spring, Click Spring $4.60 More Info
69B-600 In Stock 69B-600
069B-1184129♦
69B-600 | DSS-VP2041 Ring, Retaining Ring (E-clip)
Used on multiple models in different quantities.
$1.35 More Info
86-115L In Stock 86-115L
086-1184255
86-115L Washer, Drag, Metal, Round Keyed Metal Drag Washer ONLY

MULTI USE See Description

$1.35 More Info
98-114H2 In Stock 98-114H2
098-1198891
98-114H2 Sleeve, Gear Sleeve (comes with pin) (Brass) $18.70 More Info
98-114H2FW In Stock 98-114H2FW
098-114H2SS
98-114H2FW Sleeve, Gear Sleeve (H2,L2) 8 Tooth (Includes Pin) 304 Stainless (CUSTOM)
$39.95 More Info
102-114 In Stock 102-114
102-1192231
102-114 Pin, for gear sleeve, Pin ONLY $1.15 More Info
103N-114H2 In Stock 103N-114H2
103N-1428007
103N-114H2 Cup, Bearing Cup ONLY $14.30 More Info
110A-114H2 In Stock 110A-114H2
110A-1198893☀
110A-114H2 Cap, Handle Nut Cap $1.70 More Info
120-114H In Stock 120-114H
120-1184523☀
120-114H 'O' ring (O-ring)
114H Fits All Versions.
$1.15 More Info
149-45 In Stock 149-45
149-1184702♦
149-45 Nut, Clamp, Long, for Thick Clamps (uses 2)
Used with the graphite clamps 33-114H2, 33-340, 33N-113 and the iron alloy clamp 33i-113
$1.45 More Info
149-200 In Stock 149-200
149-1184706☀
149-200 Nut, Clamp Hex Nut (uses 2) $1.15 More Info
152-200 In Stock 152-200
152-1184709☀
152-200 Wing Nut, f/Thin Metal Rod Clamp Only (uses 2) $1.15 More Info
183-114H2 Discontinued. Not Available 183-114H2
183-1198901
183-114H2 Graphite Half Frame, 114H2 Decal More Info
168-114H2 In Stock 168-114H2
168-114H2
168-114H2 Wrench
Fits the 114H2 series of reels
$2.40 More Info
168-TANI In Stock 168-TANI
168-TANi▭
168-TANI Heavy Duty Penn Handle Nut Wrench by Alan Tani
Aftermarket Part - Not Manf. by Penn (see details for list of reels)
Fits 23-50S, 23-60, 23-114, 23-116, 23-220, 23-FTH20LW, 23-16S knurled nuts
$20.00 More Info
